Bocklet
Dakar U685

Chassis Mercedes-Benz U4000
Wheelbase 3850 mm
GVW 7.490 kg / 8.500 kg
L x W x H 6850 mm x 2350 mm x 3500 mm




Technical Data

Chassis

Chassis Mercedes-Benz U4000
Wheelbase 3850 mm
GVW 7.490 kg / 8.500 kg
Engine 4 Cylinder Turbodiesel
Capacity 4249 ccm
Engine power 160 kW / 218 PS

Body

GRP sandwich-construction, free of thermal bridges
Wall thickness 50 mm
Roof thickness 50 mm
Bottom thickness 60 mm

Interior

Length 4350 mm
Width 2200 mm
Height 1950 mm
Seats with belt -
Front bed -
Rear bed 2000 x 1350 mm



Specifications

Chassis and body

  • all-wheel-drive
  • diff-lock front- / rear axle
  • fuel tank 290 l
  • comfort seats
  • hydraulic installation with front winch 7t
  • tier pressure regulation system
  • rear view camera
  • three-point mounted, thermal bridge free GRP-Sandwichbody
  • reinforced GRP-cover layer 2mm
  • bocklet doors and hatches, free of thermal bridges
  • outer storrage space beneath rear-bed
  • underfloor storage case
  • KCT hardglas swing-out windows
  • skylight Heki 1
  • skylight Fantastic Vent
  • skylight Gebo
  • spare-wheel carrier on rear panel
  • can-carrier 2 x 20l


Interior and options

  • furniture made of 16mm wood, veneer birch
  • seat cushion cover Alcantara
  • double-floor in seating-area
  • Ebersp├Ącher Dieseln heater
  • Truma Gas- / Electric powered boiler 10l
  • battery capacity 220Ah
  • automatic charger 24 V / 50 A
  • inverter 1200 W
  • solar panels 260 W
  • control panel
  • energy saving spot lights with dimmer
  • cassette-toilett
  • white-armature with single-lever
  • 2-flame stove
  • compressor fridge 110 l
  • LCD-screen with DVD Player
  • Sat-TV
  • all tanks inside and heated:
  • freshwater 300l
  • waste water 200l
