Bocklet
Dakar 810

Chassis MAN LAEC 14.280
Wheelbase 4200 mm
GVW 11.700 kg
L x W x H 8100 mm x 2500 mm x 3750 mm




Technical Data

Chassis

Chassis MAN LAEC 14.280
Wheelbase 4200 mm
GVW 11.700 kg
Engine 6 Cylinder Turbodiesel
Capacity 6871 ccm
Engine power 206 kW / 280 PS

Body

GRP sandwich-construction, free of thermal bridges
Wall thickness 50 mm
Roof thickness 50 mm
Bottom thickness 60 mm

Interior

Length 5800 mm
Width 2400 mm
Height 2200 mm
Seats with belt 2 with 3-point belt
Front bed -
Rear bed 2000 x 1400 mm



Specifications

Chassis and body

  • all-wheel-drive
  • diff-lock rear axle
  • diff-lock front axle
  • ABS
  • fuel tank 600 l
  • comfort seatsradio CD / navigation
  • rear view camera
  • air conditoner
  • free of thermal bridges
  • cover layer 3 mm
  • bocklet doors and hatches, free of thermal bridges
  • outer storrage space on the side
  • outer storrage space beneath rear-bed
  • electric and automatic staircase
  • KCT hardglas swing-out windows
  • skylight Heki 1
  • skylight Fan Tastic Vent
  • pass to driver cab with lockable door
  • spoiler on roof top




Interior and options

  • furniture made of 16mm wood, veneer teak/ash
  • seat cushion cover microfibre
  • Ebersp├Ącher Diesel air heater
  • Alde water heater
  • battery capacity 440Ah
  • automatic charger 24 V / 70 A
  • inverter 3000 W
  • solar panels 320 W
  • control panel
  • energy saving spot lights with dimmer
  • cassette toilett
  • white-armature with single-lever
  • 3-flame stove
  • gas oven
  • compressor fridge110 l
  • all tanks inside and heated:
  • freshwater 400l
  • waste water 200l
