Bocklet
Ando 940P

Chassis Mercedes-Benz Atego 1022
Wheelbase 4820 mm
GVW 10.500 kg
L x W x H 9400 mm x 2420 mm x 3640 mm





Technical Data

Chassis

Chassis Mercedes-Benz Atego 1022
Wheelbase 4820 mm
GVW 10.500 kg
Engine 4 Cylinder Turbodiesel
Capacity 4800 ccm
Engine power 160 kW / 218 PS

Body

GRP sandwich-construction, free of thermal bridges
Wall thickness 50 mm
Roof thickness 50 mm
Bottom thickness 60 mm

Interior

Length 7500 mm
Width 2300 mm
Height 2100 mm
Seats with belt 4 with 3-point belt
Front bed 2000 x 1400 mm
Rear bed 2000 x 2000 mm



Specifications

Chassis and body

  • Telligent automatic transmission
  • diff-lock rear axle
  • ABS
  • fuel tank 180 l
  • comfort seats
  • radio CD
  • rear view camera
  • air conditioner
  • free of thermal bridges
  • bocklet doors and hatches, free of thermal bridges
  • electric and automatic staircase
  • Smart rear garage
  • skylight Heki 1
  • outer storrage space on the side
  • double-floor
  • pass to driver cab with lockable door


Interior and options

  • furniture made of 16mm wood, veneer ash grey
  • seat cushion cover leather
  • bottom cover PVC and velour
  • Ebersp├Ącher air heater
  • Alde heater with boiler
  • engine heat exchanger
  • battery capacity 440Ah, Gel
  • automatic charger 24 V / 50 A
  • inverter 3000 W
  • control panel
  • energy saving spot lights with dimmer
  • porcelain vacuum toilett
  • white-armature with single-lever
  • 3-flame stove
  • compressor fridge 190 l
  • Sat TV
  • LCD screen
  • all tanks inside and heated:
  • freshwater 350l
  • waste water 300l
  • retention tank 150l
