Bocklet
Dakar 770

Chassis MAN TGM 13.290
Wheelbase 4200 mm
GVW 13.000 kg
L x W x H 7700 mm x 2400 mm x 3750 mm








Technical Data

Chassis

Chassis MAN TGM 13.290
Wheelbase 4200 mm
GVW 13.000 kg
Engine 6 Cylinder Turbodiesel
Capacity 6871 ccm
Engine power 213 kW / 290 PS

Body

GRP sandwich-construction, free of thermal bridges
Wall thickness 51 mm
Roof thickness 51 mm
Bottom thickness 60 mm

Interior

Length 5800 mm
Width 2300 mm
Height 2100 mm
Seats with belt 2 with 3-point belt
Front bed -
Rear bed 2000 x 1800 mm



Specifications

Chassis and body

  • all-wheel-drive
  • diff-lock rear axle
  • diff-lock front axle
  • fuel tank 810 l
  • comfort seats
  • radio CD / navigation
  • rear view camera
  • air conditoner
  • free of thermal bridges
  • cover layer 3 mm
  • bocklet doors and hatches, free of thermal bridges
  • Quadgarage beneath rear-bed with electric winch
  • electric and automatic staircase
  • KCT hardglas swing-out windows
  • KCT skylight
  • roof carrier
  • storage boxes
  • awning
  • spare wheels carrier

Interior and options

  • furniture made of 16mm wood, veneer teak
  • seat cushion cover leather
  • water heater
  • battery capacity 440Ah
  • automatic charger 24 V / 70 A
  • inverter 3000 W
  • solar panels 360 W
  • control panel
  • energy saving spot lights, LED-spot lights
  • vacuum toilett
  • white-armature with single-lever
  • 3-flame stove
  • oven
  • compressor fridge 110 l
  • air conditioning
  • LED TV and automatic sat system
  • all tanks inside and heated:
  • freshwater app. 400l
  • grey water app. 250l
  • black water app.150l
