Bocklet
Dakar 615WA

Chassis Mercedes-Benz Sprinter 4x4
Wheelbase 3665 mm
GVW 3.800 kg
L x W x H 6100 mm x 2180 mm x 3050 mm




Technical Data

Chassis

Chassis Mercedes-Benz Sprinter 4x4
Wheelbase 3665 mm
GVW 3.800 kg
Engine 4 Cylinder Turbodiesel
Capacity 2143 ccm
Engine power 120/163 kW/PS

Body

kältebrückenfreie GFK- Sandwich-Konstruktion
Wall thickness 50 mm
Roof thickness 50 mm
Bottom thickness 60 mm

Interior

Length 3550 mm
Width 2050 mm
Height 1950 mm
Seats with belt 2 mit Dreipunktgurt
Front bed -
Rear bed 2000 x 1350 mm



Specifications

Chassis and body

  • all-wheel-drive
  • fuel tank 100 l
  • comfort seats
  • radio CD, bluetooth
  • rear view camera
  • free of thermal bridges
  • cover layer 2mm
  • bocklet doors and hatches, free of thermal bridges
  • outer storrage space on the side
  • outer storrage space beneath rear bed
  • electric and automatic stair case
  • KCT hardglas swing-out windows
  • skylight seitz Heki 1
  • skylight Gebo
  • pass to driver cab with lockable door
  • roof carrier with swing-out
  • Dachluke Fan Tastic Vent
  • sand plate
  • storrage box on roof carrier


Interior and options

  • furniture made of 16mm bi-coloured wood, veneer oak
  • seat cover
  • double-floor in seating area
  • gas heater Truma Combi C4E
  • battery capacity 220Ah
  • automatic charger 12 V / 50 A
  • inverter 2000 W
  • solar panels 320 W
  • control panel
  • energy saving lights and LED lights
  • cassette toilett
  • white-armature with single-lever
  • 2-flame stove
  • compressor fridge 80 l
  • all tanks inside and heated:
  • freshwater 200l
  • waste water 115l
  • countertop mineralstone
